Triple Offset Butterfly Valve
Quick Advantages
Why Choose Triple Offset Butterfly Valves
Engineered for metal-to-metal sealing, high temperature resistance, high pressure capability, and severe service shut-off in critical process systems.
Metal-to-Metal Sealing
Designed for tight shut-off performance in demanding applications where resilient seated valves may not provide sufficient durability.
High Temperature Resistance
Suitable for elevated temperature service involving steam, hot gas, thermal process media, and severe operating environments.
High Pressure Capability
Built for systems requiring dependable shut-off integrity and stable performance under higher pressure operating conditions.
Severe Service Applications
Widely used in oil & gas, petrochemical, refinery, power generation, and industrial process lines where critical isolation is required.
Overview
What Is a Triple Offset Butterfly Valve?
A triple offset butterfly valve is a metal seated quarter-turn valve designed with three offsets in its shaft and sealing geometry. This structure creates a non-rubbing sealing motion during operation and supports tight shut-off in severe service conditions.
Unlike resilient seated butterfly valves, triple offset designs are intended for high temperature, high pressure, and demanding process duty where metal-to-metal sealing reliability is required. They are commonly selected for critical isolation in systems where seat durability and shut-off integrity are essential.
Triple offset butterfly valves can be supplied in different body materials, sealing constructions, and actuation methods to match operating temperature, pressure class, media characteristics, and project specifications.
Metal-to-Metal Sealing
Engineered for tight shut-off in demanding service where resilient seat construction may not provide sufficient durability.
Reduced Sealing Wear
The triple offset geometry helps minimize friction between sealing surfaces during opening and closing.
Severe Service Applications
Widely used in oil & gas, petrochemical, refinery, power generation, and industrial process lines where critical isolation is required.
Configurations
Available Triple Offset Butterfly Valve Configurations
We supply triple offset butterfly valves in multiple operation and application configurations for metal seated shut-off, high temperature service, and severe process conditions.
Gear Operated Triple Offset Butterfly Valve
Recommended for medium and larger sizes where stable manual operation, controlled closing torque, and dependable shut-off are required.
Pneumatic Triple Offset Butterfly Valve
Designed for fast automated shut-off in critical process systems requiring responsive control and severe service isolation.
Electric Triple Offset Butterfly Valve
Ideal for monitored systems and installations requiring stable motorized actuation in high temperature and demanding operating environments.
High Temperature Triple Offset Butterfly Valve
Suitable for elevated temperature applications where metal-to-metal sealing, shut-off integrity, and long-term durability are critical.
Key Features
Designed for Severe Service and Tight Shut-Off Performance
Triple offset butterfly valves are engineered for metal-to-metal sealing, high temperature resistance, and dependable shut-off in severe service conditions. Their three-offset geometry helps reduce sealing wear and supports long-term reliability in demanding process systems.
Metal-to-Metal Sealing
Designed for tight shut-off duty where resilient seat construction may not provide sufficient durability.
High Temperature Resistance
Suitable for steam, hot gas, and elevated process temperature applications requiring metal seated reliability.
High Pressure Capability
Built for demanding systems where shut-off integrity and stable performance under pressure are essential.
Reduced Sealing Wear
The triple offset geometry helps minimize friction between sealing surfaces during opening and closing.
Multiple Operation Choices
Available with gear, pneumatic, and electric actuation to match different control requirements.
Severe Service Applications
Widely used in oil & gas, petrochemical, refinery, power generation, and industrial process lines requiring critical isolation.
Technical Specifications
Technical Specifications
Standard ranges can be customized according to project requirements, media conditions, pressure class, temperature range, and applicable standards.
Selection Overview
Triple offset butterfly valves can be supplied in different materials, sealing constructions, pressure classes, and operation methods to match metal seated shut-off, high temperature service, and severe operating conditions.
- Typical Applications
Oil & gas, petrochemical, refinery, power generation, steam service, hot gas systems, and critical industrial process lines.
- Available Configurations
Gear operated, pneumatic actuator, and electric actuator.
- Custom Support
Materials, pressure class, dimensions, sealing construction, and actuation packages can be matched to project requirements.
Item
Specification
Valve Type
Triple Offset Butterfly Valve
Seat Type
Metal Seated
Size Range
DN80–DN2000
Pressure Rating
Class 150 / 300 / 600 or project-based
Body Material
Carbon Steel, Stainless Steel, Alloy Steel
Disc Material
Stainless Steel, Alloy Steel
Seat Material
Metal Seat / Hardfaced Seat / Project-Based
Stem Material
Stainless Steel / Alloy Steel
Operation
Gear, Pneumatic, Electric
Applicable Media
Steam, Hot Gas, Oil, Hydrocarbon, Process Fluids
Temperature Range
According to material selection and service condition
Standards
API, ANSI, ASME, DIN, BS, JIS
Leakage Requirement
According to project specification and testing standard
Custom sizes, materials, pressure classes, sealing constructions, and actuator packages are available upon request. You can also replace the values above with your factory’s actual specification range.
Materials & Seat Options
Material Choices for Different Service Conditions
Different material combinations help improve sealing reliability, temperature resistance, wear performance, and long-term service life in severe operating conditions.
Seat Materials
Seat and sealing construction are critical in triple offset butterfly valves because they directly affect shut-off integrity, media suitability, temperature capability, and long-term wear resistance. Different sealing options should be selected according to process conditions and project requirements.
Metal Seat
Suitable for high temperature and severe service applications requiring metal-to-metal sealing and dependable shut-off performance.
Hardfaced Seat
Overlay materials such as hardfacing can be used to improve wear resistance and sealing durability in demanding process conditions.
High Temperature Selection
Material combinations can be selected for steam, hot gas, thermal process media, and elevated temperature service environments.
Customized Construction
Seat and sealing construction can be matched according to leakage requirement, operating temperature, media condition, and project specification.
Body Materials
Body materials are selected according to pressure class, temperature range, corrosion environment, and overall plant service conditions. Different metal grades are available for severe service and critical isolation duty.
Disc Materials
Disc material affects shut-off durability, thermal stability, corrosion resistance, and long-term operating performance. Selection should match media characteristics and service severity.
Applications
Typical Applications
Triple offset butterfly valves are widely used in systems where metal-to-metal sealing, high temperature resistance, and severe service shut-off reliability are required.
Critical Process Isolation
Triple offset butterfly valves are widely used in critical process lines because their metal seated design and triple offset geometry support tight shut-off, reduced sealing wear, and dependable performance under demanding temperature and pressure conditions.
Oil & Gas Processing
Used in hydrocarbon and process systems where shut-off integrity, severe service reliability, and metal seated performance are critical.
Petrochemical Plants
Suitable for elevated temperature and demanding media conditions where resilient seated valves may not provide sufficient durability.
Power Generation
Applied in steam, hot gas, and high temperature utility systems requiring metal seated durability and reliable shut-off.
Refinery Service
Used in severe operating environments where long-term shut-off performance and reduced sealing wear are essential.
Application suitability depends on temperature, pressure, media condition, leakage requirement, and material selection. Customized recommendations can be provided based on project conditions.
Actuation Options
Operation and Actuation Options
Triple offset butterfly valves can be supplied with manual or automated operation to match critical shut-off requirements, severe service duty, and plant process control systems.
The right actuation method depends on valve size, torque requirement, operating frequency, installation position, and whether local or remote control is needed.
- Manual or Automated
Available for critical shut-off, frequent operation, or integrated control systems in demanding plant environments.
- Project-Based Selection
Actuation options can be matched according to valve size, torque requirement, service condition, and control method.
- Flexible Supply Scope
Complete valve and actuator assemblies can be supplied for easier installation, commissioning, and project integration.
Gear Operated
Recommended for medium and larger sizes where stable manual operation, controlled closing torque, and dependable shut-off are required.
Pneumatic Actuated
Suitable for fast automated shut-off in critical process systems requiring responsive control and severe service isolation.
Electric Actuated
Ideal for remote operation, monitored systems, and installations requiring stable motorized actuation in demanding operating environments.
Project-Based Packages
Actuator and accessory packages can be configured according to plant control requirements, site conditions, and project specifications.
Actuation options can be configured according to valve size, torque requirement, control method, and project specification.
Why Choose Raymon Valve
Project-Based Configuration
Valve material, sealing construction, pressure class, and actuation method can be matched to high temperature, high pressure, and severe service requirements.
Engineering Support
Selection support is available for metal seated shut-off, critical isolation, leakage requirement, and demanding process conditions.
Technical Documents
Technical data, drawings, and inspection-related documents can be supported for project supply, export requirements, and engineering review.
Fast Response
Quick follow-up for RFQ, engineering questions, material confirmation, and triple offset butterfly valve selection support.
Featured Products
Featured Triple Offset Butterfly Valve Products
Explore selected triple offset butterfly valve models for metal seated shut-off, high temperature service, and severe process isolation requirements.
Gear Operated Triple Offset Butterfly Valve
A practical choice for medium and large sizes requiring stable manual operation, controlled closing torque, and dependable shut-off performance.
Pneumatic Triple Offset Butterfly Valve
Designed for fast automated isolation in critical process systems requiring responsive control and severe service shut-off reliability.
Electric Triple Offset Butterfly Valve
Ideal for remote operation, monitored systems, and applications requiring stable motorized actuation in demanding operating environments.
High Temperature Triple Offset Butterfly Valve
Suitable for elevated temperature applications where metal-to-metal sealing, shut-off integrity, and long-term durability are critical.
FAQ
Frequently Asked Questions
Common questions about triple offset butterfly valve selection, configuration, and application.
What is a triple offset butterfly valve?
A triple offset butterfly valve is a metal seated butterfly valve designed with three offsets in its shaft and sealing geometry. This design helps reduce friction during operation and supports tight shut-off in severe service conditions.
Why use a triple offset butterfly valve instead of a resilient seated butterfly valve?
Triple offset butterfly valves are typically selected for higher temperature, higher pressure, and more severe operating conditions where resilient seated designs may not provide sufficient durability or shut-off reliability.
Are triple offset butterfly valves suitable for zero-leakage shut-off?
They are commonly engineered for tight shut-off or zero-leakage performance where specified, but actual performance should be defined according to valve design, testing standard, and project requirement.
What industries commonly use triple offset butterfly valves?
They are widely used in oil & gas, petrochemical, refinery, power generation, and industrial process systems requiring critical isolation.
Are triple offset butterfly valves suitable for high temperature service?
Yes. They are commonly used in high temperature applications because of their metal seated construction and severe service design. Final suitability depends on material selection and operating conditions.
How do I choose the right triple offset butterfly valve?
You should confirm valve size, pressure class, media type, operating temperature, leakage requirement, material selection, and actuation method to determine the most suitable configuration.
