Globe valves
INDUSTRIAL GLOBE VALVE SOLUTIONS
Industrial Globe Valves Manufacturer & Supplier
Raymon Valve supplies industrial globe valves for flow regulation, throttling, and reliable shut-off in steam, oil & gas, chemical processing, power generation, water treatment, and general industrial piping systems.
Browse globe valves by body pattern, pressure rating, material, end connection, sealing design, and operation method.
Flow Regulation Service
Flanged & Welded Ends
Carbon Steel & Stainless Steel
Manual, Electric & Pneumatic Operation
Size Range
DN15–DN600 / 1/2"–24"
Pressure Rating
PN16–PN420 / Class 150–2500
Body Materials
WCB / CF8 / CF8M / Alloy Steel
Standards
API / ANSI / DIN / BS / JIS / GB
QUICK VALVE FINDER
Find the Right Globe Valve for Your Application
Use the quick links below to explore globe valves by body design, pressure rating, material, sealing structure, connection type, and working condition.
Connection Type
Reliable globe valves with flanged ends for steam, water, oil, gas, chemical processing, and general industrial pipeline systems.
High Pressure Service
Forged Steel Globe Valves
Compact forged body globe valves designed for high-pressure, high-temperature, small-bore, steam, refinery, and power plant applications.
Material Selection
Corrosion-resistant globe valves for chemical media, water treatment, marine service, clean fluids, and general process applications.
Low Emission Service
Designed to reduce stem leakage in steam, thermal oil, toxic, volatile, and environmentally sensitive media applications.
Piping Layout
Angle body globe valves provide shut-off and flow control while changing the flow direction by 90 degrees in compact piping layouts.
Lower Pressure Drop
Y-Pattern Globe Valves
Y-pattern globe valves are suitable for high-pressure or high-flow systems where reduced pressure drop and stable flow performance are required.
GLOBE VALVE CATEGORIES
Browse Our Industrial Globe Valve Range
Raymon Valve offers a full range of industrial globe valves for throttling, flow regulation, shut-off, steam service, high-pressure pipelines, corrosive media and project-specific applications.
01
GENERAL SERVICE
Flanged Globe Valves
General-purpose globe valves with flanged ends for steam, water, oil, gas, chemical processing and industrial utility pipelines.
02
HIGH PRESSURE
Forged Steel Globe Valves
Compact forged steel globe valves designed for high-pressure, high-temperature, small-bore, steam, refinery and power plant service.
03
CORROSIVE MEDIA
Stainless Steel Globe Valves
Corrosion-resistant globe valves for chemical media, water treatment, marine service, clean fluids and general process applications.
04
LOW EMISSION
Bellows Sealed Globe Valves
Designed to reduce stem leakage in steam, thermal oil, toxic, volatile and environmentally sensitive media applications.
05
COMPACT PIPING
Angle Globe Valves
Angle body globe valves provide shut-off and flow control while changing the flow direction by 90 degrees in compact piping layouts.
06
LOWER PRESSURE DROP
Y-Pattern Globe Valves
Y-pattern globe valves are suitable for high-pressure or high-flow systems where reduced pressure drop and stable flow performance are required.
BY STRUCTURE & SEALING DESIGN
Choose the Right Globe Valve by Flow Control, Leakage Requirement and Piping Layout
Different globe valve structures provide different flow control performance, pressure drop characteristics, leakage control and installation flexibility. Select the proper body pattern and sealing design according to media condition, operating temperature, pressure class and maintenance requirement.
SELECTION LOGIC
Match Valve Structure to Pressure Drop, Leakage Control and Service Duty
From standard straight-pattern globe valves to angle, Y-pattern and bellows sealed designs, the correct globe valve selection depends on flow regulation accuracy, system pressure drop, emission control requirement, temperature range and pipeline arrangement.
General Regulation Standard Globe Valve
Compact Piping Layout Angle Globe Valve
Lower Pressure Drop Y-Pattern Globe Valve
Low Emission Service Bellows Sealed Design
STANDARD FLOW CONTROL
Standard Globe Valves
Straight-pattern globe valves are widely used for throttling, flow regulation and shut-off in steam, water, oil, gas and general industrial pipelines.
TYPICAL USE
Steam, Water, Oil & Utility Lines
01
COMPACT PIPE ROUTING
Angle Globe Valves
Angle globe valves combine flow control and 90-degree direction change, helping simplify piping layouts where space or installation direction is limited.
Typical Use
Compact Layouts, Steam & Drain Lines
02
LOWER PRESSURE DROP
Y-Pattern Globe Valves
Y-pattern globe valves are designed to reduce flow resistance compared with standard globe valves, making them suitable for high-pressure or high-flow systems.
Typical Use
High-Pressure Steam & Power Systems
03
LOW EMISSION DESIGN
Bellows sealed globe valves use a metal bellows structure to reduce stem leakage in toxic, volatile, high-temperature or environmentally sensitive media.
Typical Use
Steam, Thermal Oil & Hazardous Media
04
BY END CONNECTION TYPE
Select Globe Valves by Pipeline Connection Method
Choose the end connection type that best fits your pipeline standard, pressure class, temperature condition, maintenance requirement and installation method. Different connection designs affect sealing reliability, installation cost, maintenance access and long-term service performance.
Maintenance Friendly
Flanged Type
High Temperature Lines
Butt Weld Type
Small-Bore Piping
Socket Weld / Threaded Type
Project Customization
Special End Designs
Flanged Globe Valves
Flanged globe valves are the most common choice for industrial piping systems where easy installation, inspection and maintenance are required. They are suitable for steam, water, oil, gas, chemical processing and general utility service.
TYPICAL USE
Steam, Water, Oil & General Industrial Lines
Butt weld globe valves are selected for high-pressure, high-temperature and critical process pipelines where welded connections provide strong structural integrity and reduced external leakage points.
Typical Use
Steam Lines, Power Plants, Refinery Systems
Socket Weld & Threaded Globe Valves
Socket weld and threaded globe valves are compact options for small-bore piping systems. They are commonly used in high-pressure auxiliary lines, instrument connections, utility systems and equipment package piping.
Typical Use
Small-Bore Lines, Utility Piping, Equipment Packages
Special End Designs
Custom end connections are available for project-specific requirements, international piping standards, special installation conditions and export valve applications. Options can be configured according to flange standard, welding standard, face-to-face dimension and material specification.
Availability
Options Available on Request
BY OPERATION & ACTUATION
Manual and Automated Globe Valve Solutions
Raymon Valve supplies globe valves for standard manual operation, remote shut-off, flow regulation and automated process control systems. Select the operation method according to valve size, pressure class, operating frequency, control accuracy and site automation requirements.
Basic Shut-Off
Manual Operation
Process Automation
Pneumatic Actuation
Remote Control
Electric Actuation
Project Integration
Custom Packages
Manual Globe Valves
Manual globe valves are operated by handwheel and are suitable for standard shut-off, throttling and flow adjustment in industrial piping systems. They are commonly used where operation frequency is moderate and local manual control is acceptable.
Typical Use
Steam, Water, Utility Lines and General Flow Regulation
Pneumatic Globe Valves
Pneumatic globe valves are suitable for automated process lines where fast response, frequent operation and integration with plant air systems are required. They can be configured for on-off control or modulating flow control according to project demand.
Typical Use
Process Systems, Fast Cycling, Remote Shut-Off
Electric Globe Valves
Electric globe valves provide reliable remote operation for industrial pipelines, utility systems and automated process control. They are a practical choice where electric power is available and stable open-close or modulating control is required.
Typical Use
Remote Operation, Utility Control, Process Lines
Custom Actuation Packages
Actuator, positioner, limit switch, solenoid valve, air filter regulator and control accessories are available according to valve size, torque requirement, control logic, installation environment and project specification.
Available Options
Pneumatic Actuator, Electric Actuator, Positioner, Limit Switch, Solenoid Valve
SOLUTIONS BY WORKING CONDITION
Globe Valve Options for Demanding Service Conditions
We help customers select the appropriate globe valve design, body material, trim material and sealing structure according to media type, temperature, pressure, leakage requirement and operating environment.
SELECTION FOCUS
Choose the Right Globe Valve by Media, Pressure and Service Duty
Working condition has a direct impact on globe valve body material, trim selection, bonnet design, packing structure and expected service life. Before selecting a globe valve, the actual media, temperature, pressure class, flow regulation requirement and leakage control demand should be reviewed carefully.
Temperature Range Ambient to High Temperature Service
Pressure Class PN16 to PN420 / Class 150 to Class 2500
Control Duty Shut-Off / Throttling / Frequent Operation
Leakage Control Standard Packing / Bellows Sealed Design
High Temperature Service
Globe valves for high-temperature service require suitable body material, trim material, bonnet structure and packing selection. They are commonly used in steam, thermal oil, boiler systems, power generation and refinery process lines.
RECOMMENDED DESIGN DIRECTION
Alloy Steel, Butt Weld Ends, Hard-Faced Trim, Pressure Seal or Bolted Bonnet
Corrosive Media
Stainless steel, duplex stainless steel or special alloy globe valves are recommended for corrosive media, chemical processing, seawater, acid, alkali and other aggressive service environments.
Typical Focus
Stainless Steel, Duplex Steel, Alloy Materials, Corrosion-Resistant Trim
High Pressure Service
High-pressure globe valves are selected for steam systems, refinery units, power plants and process pipelines where pressure rating, body strength, bonnet design and seat sealing reliability are critical.
Typical Focus
Forged Steel Body, Pressure Seal Bonnet, Butt Weld Ends, High-Strength Trim
Flow Regulation Duty
For throttling and frequent flow adjustment, globe valve disc design, seat material, stem strength and actuator matching should be selected according to pressure drop, flow rate and operating frequency.
Typical Focus
Stable Throttling, Replaceable Trim, Manual or Actuated Control
Low Emission Service
Bellows sealed globe valves are used when external stem leakage must be minimized. They are suitable for toxic, volatile, expensive, high-temperature or environmentally sensitive media.
Typical Focus
Bellows Sealed Design, Stem Leakage Control, Safer Media Handling
Severe Service Applications
Special globe valve designs are available for high pressure, high temperature, frequent throttling, erosive flow, corrosive media and other demanding industrial conditions where standard valve configurations may not provide sufficient durability.
Typical Focus
Hard-Faced Trim, Alloy Body, Special Packing, Project-Specific Design
INDUSTRY APPLICATIONS
Globe Valves for Key Industrial Applications
Our globe valves are used across a wide range of industries where dependable shut-off, accurate flow regulation and long service life are required. Explore the main application sectors below to identify suitable globe valve solutions for your system.
Utility Systems
Water / HVAC / Municipal
Process Industry
Chemical / Power
Heavy Duty Service
Mining / General Industry
Water Treatment
Globe valves are used in water treatment systems for chemical dosing, transfer lines, utility service and controlled flow applications where dependable shut-off, stable regulation and corrosion resistance are important.
Typical Need
Reliable Regulation, Corrosion Resistance, Easy Maintenance
Municipal Water Supply
Globe valves are suitable for municipal water systems, pump stations and infrastructure utility lines where stable control, dependable shut-off and long-term service reliability are required.
Typical Need
Large Diameter, Stable Connection, Long Service Life
HVAC & Building Services
Globe valves are commonly used in chilled water, hot water, steam and building utility systems where flow adjustment, balancing and routine shut-off are required for daily operation.
Typical Need
Flow Control, Easy Operation, Utility System Stability
Chemical Processing
Corrosion-resistant globe valves are used in chemical process lines, dosing systems and aggressive media service where material compatibility, controlled flow and leakage reliability are critical.
Typical Need
Corrosion Resistance, Material Compatibility, Leakage Control
Power Generation
Globe valves are widely used in steam systems, condensate lines, auxiliary piping and selected power plant services requiring dependable shut-off, throttling capability and stable performance.
Typical Need
High Temperature Capability, Stable Operation, System Reliability
Mining & General Industry
Heavy-duty globe valves can be used in industrial utility lines, process support systems and selected demanding service environments where durable construction and dependable control performance are required.
Typical Need
Durability, Service Reliability, Stronger Valve Structure
Need help matching industry conditions with the right globe valve solution?
Technical Overview
Globe Valve Specifications and Manufacturing Capability
Our globe valve range is available in multiple materials, pressure ratings, body patterns and end connections to meet industrial flow control, shut-off and throttling requirements. Review the core technical parameters and manufacturing scope below.
Technical Data Matrix
GV / Industrial Range
Size Range
DN15–DN600 / 1/2"–24"
Pressure Rating
PN16–PN420 / Class 150–2500
Body Materials
WCB, WCC, LCB, CF8, CF8M, CF3M, Alloy Steel
Trim Materials
13Cr, SS304, SS316, Stellite, Monel, Inconel
Bonnet Design
Bolted Bonnet, Welded Bonnet, Pressure Seal, Bellows Sealed
Connection Standards
Flanged, Butt Weld, Socket Weld, Threaded
Design & Testing
API, ANSI, ASME, DIN, EN and customer-specified standards
Operation Options
Handwheel, Gear Operator, Pneumatic, Electric
Engineered for Flow Control and Severe Service Conditions
From standard flanged globe valves to forged steel, bellows sealed, angle and Y-pattern designs, Raymon Valve provides technical support for material selection, trim design, pressure rating, end connection, actuation matching and project-standard compliance.
Material Flexibility
Body, bonnet, disc, seat and stem materials can be selected according to media, temperature, pressure and corrosion requirements.
Multi-Standard Production
Support for international connection, face-to-face, pressure rating, inspection and testing requirements.
Actuation Compatibility
Manual, pneumatic and electric operation options are available for shut-off, throttling and automated control systems.
Project Customization
Customized body pattern, trim material, sealing structure, end connection and documentation packages for industrial projects.
Need help matching technical requirements with the right globe valve design?
Why Raymon Valve
Why Customers Source Globe Valves from Raymon Valve
We support industrial customers, distributors, contractors and project buyers with a broad globe valve range, flexible manufacturing capability and responsive technical service for international supply requirements.
Product Coverage
Standard, High Pressure & Severe Service
Standards
ANSI / API / ASME / DIN / EN / JIS / GB
Support Scope
Selection, Testing, Export Coordination
Raymon Advantage
Built for Industrial Procurement and Project Supply
Raymon Valve supports customers who need practical globe valve solutions, stable production capability, flexible standards coverage and clear technical communication across industrial and export projects.
Core Value
Reliable Supply, Broader Range, Stronger Technical Coordination
Product Breadth
Wide Product Range
From flanged and forged steel globe valves to stainless steel, bellows sealed, angle and Y-pattern designs for different industrial applications.
Flexible Manufacturing
Custom Manufacturing Support
Custom sizes, materials, trim options, end connections, bonnet structures and actuator packages are available for project-based sourcing needs.
International Requirements
Multi-Standard Production
Support for ANSI, API, ASME, DIN, EN, JIS and GB standards to match international project requirements and regional procurement preferences.
Verification Support
Inspection & Testing Support.
Material certificates, shell pressure tests, seat leakage tests and third-party inspection support are available according to customer or project requirements.
Export Coordination
Export Experience
Packaging, documentation and shipping coordination support overseas procurement, distributor supply and project delivery requirements.
Technical Response
Fast Technical Response
Our team helps evaluate working conditions and recommend suitable globe valve solutions for pressure, temperature, media, connection and actuation requirements.
Need application-based sourcing support?
Tell us your valve size, pressure, medium, standard, connection type and actuation requirements.
Application Experience
Globe Valve Solutions for Real Industrial Projects
Our globe valves are applied in steam systems, chemical processing, power generation, water treatment, oil & gas and general industrial projects where reliable shut-off, stable flow regulation and long-term service performance are required.
Cast Steel Flanged Globe Valve
A widely used globe valve solution for steam, water, oil, gas and general industrial process lines where flow regulation, reliable shut-off and easy maintenance are required.
Size DN15–DN600
Pressure Rating PN16–PN420 / Class 150–2500
Body Material WCB / CF8 / CF8M / Alloy Steel
Operation Handwheel / Gear / Electric / Pneumatic
Forged Steel Globe Valve
Pressure: Class 800 / 1500 / 2500
Application: High Pressure Steam Service
Bellows Sealed Globe Valve
Sealing: Bellows Sealed Stem
Application: Low Emission Service
Stainless Steel Globe Valve
Connection: Flanged / Welded / Threaded
Application: Corrosive Media Service
Y-Pattern Globe Valve
Service: Steam / Power / High Flow Lines
Application: High Pressure Systems
Need application-based sourcing support?
Tell us your valve size, pressure, medium, standard, connection type and actuation requirements.
Why Raymon Valve
Practical Globe Valve Supply Experience for Industrial Projects
Raymon Valve supports industrial customers, distributors, contractors and project buyers with globe valve solutions for steam, process, chemical, power, water and general industrial pipeline systems.
Practical Valve Supply Experience for Steam, Process and Industrial Systems
Raymon Valve supports customers across steam, chemical, power, water treatment, oil & gas and industrial utility projects where globe valves must match pressure rating, temperature, media condition, end connection, leakage requirement and procurement standards.
- Application Scope
- Steam, Water, Oil, Gas, Chemical and Utility Service
- Supply Focus
- Shut-Off, Throttling, Flow Regulation and Low Emission Service
- Project Support
- Selection, Material Matching, Testing and Export Coordination
- Buyer Types
- Distributors, Contractors, EPC Projects and Industrial End Users
Steam and Process Pipeline Systems
Globe valves are widely used in steam, condensate, thermal oil and process pipelines where stable flow regulation, reliable shut-off and high-temperature performance are required.
Typical Project Focus
High Temperature, Flow Regulation, Flanged or Butt Weld Connection
Water, HVAC and Utility Lines
Globe valves are suitable for water systems, chilled water, hot water, building utility pipelines and general service lines where routine shut-off and controlled flow adjustment are required.
Typical Project Focus
Stable Operation, Easy Maintenance, Manual Flow Control
Chemical, Power and Severe Service Applications
For chemical processing, power generation and demanding industrial systems, globe valves can be supplied with suitable body materials, trim options, bonnet structures and sealing designs according to actual working conditions.
Typical Project Focus
Corrosion Resistance, High Pressure, High Temperature and Low Emission Design
Need project-based valve selection support?
Share your project conditions and our team will help match the right globe valve solution.
Globe Valves: Ultimate Guide
WHAT IS A GLOBE VALVE USED FOR?
A globe valve is used for shut-off, throttling and flow regulation in industrial piping systems. It is commonly applied in steam, water, oil, gas, chemical processing, power generation and general utility lines where stable control and reliable sealing are required.
WHEN SHOULD I CHOOSE A GLOBE VALVE INSTEAD OF A GATE VALVE?
Choose a globe valve when the system requires flow regulation or frequent adjustment. Gate valves are mainly used for fully open or fully closed service, while globe valves provide better throttling control but usually create a higher pressure drop.
CAN GLOBE VALVES BE USED FOR THROTTLING SERVICE?
Yes. Globe valves are one of the most common valve types for throttling service. The disc moves directly against the seat, allowing more gradual flow adjustment than many quarter-turn valves.
WHAT IS THE DIFFERENCE BETWEEN STANDARD, ANGLE AND Y-PATTERN GLOBE VALVES?
Standard globe valves are used for general flow regulation and shut-off. Angle globe valves change the flow direction by 90 degrees and can simplify compact piping layouts. Y-pattern globe valves reduce flow resistance and are often selected for high-pressure or high-flow systems.
WHEN IS A BELLOWS SEALED GLOBE VALVE REQUIRED?
WHAT MATERIALS ARE AVAILABLE FOR GLOBE VALVES?
Common globe valve materials include carbon steel, forged steel, stainless steel, alloy steel, duplex stainless steel and special alloys. The correct material depends on pressure, temperature, media corrosion, leakage requirement and project specification.
CAN YOU SUPPLY PNEUMATIC AND ELECTRIC ACTUATED GLOBE VALVES?
Yes. Raymon Valve can supply globe valves with manual handwheel operation, pneumatic actuators and electric actuators. Actuator selection depends on valve size, pressure class, control type, operating frequency and automation requirements.
WHAT INFORMATION IS NEEDED FOR GLOBE VALVE SELECTION?
To select the right globe valve, please provide pipe size, pressure rating, working temperature, medium, connection standard, body material, trim requirement, operation method and quantity. For severe service, leakage requirement and pressure drop should also be reviewed.
WHAT STANDARDS CAN YOUR GLOBE VALVES COMPLY WITH?
Raymon Valve can supply globe valves according to common international and project-specified standards, including ANSI, API, ASME, DIN, EN, JIS and GB requirements. Inspection, testing and documentation can be arranged according to order requirements.
CAN YOU PROVIDE CUSTOMIZED GLOBE VALVES?
Yes. Customized globe valves are available for special materials, trim designs, end connections, bonnet structures, pressure ratings, actuation packages and project documentation requirements.
English
German
Arabic
French
Spanish
Italian
Portuguese
Russian
